yum install -y python3-devel

pip3 install git+https://github.com/marin-m/vmlinux-to-elf


[root@localhost ~]# vmlinux-to-elf /usr/lib/debug/lib/modules/3.10.0-229.1.2.el7.x86_64/vmlinux vmlinux.elf
[+] Version string: Linux version 3.10.0-229.1.2.el7.x86_64 ([email protected]) (gcc version 4.8.2 20140120 (Red Hat 4.8.2-16) (GCC) ) #1 SMP Fri Mar 27 03:04:26 UTC 2015
[+] Guessed architecture: x86_64 successfully in 3.01 seconds
[+] Found kallsyms_token_table at file offset 0x00a13598
[+] Found kallsyms_token_index at file offset 0x00a13928
[+] Found kallsyms_markers at file offset 0x00a12d08
[+] Found kallsyms_names at file offset 0x00946478 (69961 symbols)
[+] Found kallsyms_num_syms at file offset 0x00946470
[i] Null addresses overall: 0.00285874 %
[+] Found kallsyms_addresses at file offset 0x008bda28
[+] Successfully wrote the new ELF kernel to vmlinux.elf





cd /serverspeeder/bin
bin="acce-3.10.61.12-[CentOS_3.10.0-229.1.2.el7.x86_64]"
gdb -q "./$bin"

# 1）如果程序会 fork（很多这类安装器会），建议先跟踪子进程
set follow-fork-mode child
set detach-on-fork off

# 2）设置 syscall 断点
catch syscall init_module


# 3）直接跑程序（不要用 start，用 run）
run
# 应该能看到下面的内容
# Starting program: /serverspeeder/bin/./acce-3.10.61.12-[CentOS_3.10.0-229.1.2.el7.x86_64]
# (license 7603574CEB4C8210d3fb605d)
# Catchpoint 1 (call to syscall init_module), 0x00000000004b2f3a in ?? ()

info registers rdi rsi rdx
#应该看到：
# rdi = 0x0000000000403000（或者你 strace 里看到的那个地址，比如 0x403000）
# rsi = 439240（长度）
# rdx 指向 "engineId=0 cpuId=0 cpuMaskNum=1" 字符串

#确认是这次 init_module 之后，按下面步骤 dump：
# 定义起始和结束地址
set $addr = (void*)$rdi
set $len = $rsi
set $end = $addr + $len

# 把这一段写到当前目录的文件里
dump memory appex_module.bin $addr $end
#然后退出 gdb：
quit

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66

[root@localhost bin]# file appex_module.bin
appex_module.bin: ELF 64-bit LSB relocatable, x86-64, version 1 (SYSV), BuildID[sha1]=4198d57426226e1e8e03ec63c34e0188b8cebdab, not stripped
[root@localhost bin]#
[root@localhost bin]# readelf -h appex_module.bin
ELF Header:
Magic: 7f 45 4c 46 02 01 01 00 00 00 00 00 00 00 00 00
Class: ELF64
Data: 2's complement, little endian
Version: 1 (current)
OS/ABI: UNIX - System V
ABI Version: 0
Type: REL (Relocatable file)
Machine: Advanced Micro Devices X86-64
Version: 0x1
Entry point address: 0x0
Start of program headers: 0 (bytes into file)
Start of section headers: 305040 (bytes into file)
Flags: 0x0
Size of this header: 64 (bytes)
Size of program headers: 0 (bytes)
Number of program headers: 0
Size of section headers: 64 (bytes)
Number of section headers: 37
Section header string table index: 34
[root@localhost bin]#
[root@localhost bin]# readelf -S appex_module.bin | head -40
There are 37 section headers, starting at offset 0x4a790:

Section Headers:
[Nr] Name Type Address Offset
Size EntSize Flags Link Info Align
[ 0] NULL 0000000000000000 00000000
0000000000000000 0000000000000000 0 0 0
[ 1] .note.gnu.build-i NOTE 0000000000000000 00000040
0000000000000024 0000000000000000 A 0 0 4
[ 2] .text PROGBITS 0000000000000000 00000070
0000000000040c2b 0000000000000000 AX 0 0 16
[ 3] .rela.text RELA 0000000000000000 00051448
00000000000157f8 0000000000000018 35 2 8
[ 4] .text.unlikely PROGBITS 0000000000000000 00040c9b
000000000000158e 0000000000000000 AX 0 0 1
[ 5] .rela.text.unlike RELA 0000000000000000 00066c40
00000000000002b8 0000000000000018 35 4 8
[ 6] .altinstr_replace PROGBITS 0000000000000000 00042229
0000000000000006 0000000000000000 AX 0 0 1
[ 7] .init.text PROGBITS 0000000000000000 0004222f
00000000000004d2 0000000000000000 AX 0 0 1
[ 8] .rela.init.text RELA 0000000000000000 00066ef8
00000000000006f0 0000000000000018 35 7 8
[ 9] .rodata PROGBITS 0000000000000000 00042720
0000000000002620 0000000000000000 A 0 0 32
[10] .rela.rodata RELA 0000000000000000 000675e8
0000000000001020 0000000000000018 35 9 8
[11] __mcount_loc PROGBITS 0000000000000000 00044d40
0000000000000a78 0000000000000000 A 0 0 8
[12] .rela__mcount_loc RELA 0000000000000000 00068608
0000000000001f68 0000000000000018 35 11 8
[13] .rodata.str1.1 PROGBITS 0000000000000000 000457b8
00000000000014f9 0000000000000001 AMS 0 0 1
[14] .rodata.str1.8 PROGBITS 0000000000000000 00046cb8
0000000000000c59 0000000000000001 AMS 0 0 8
[15] .smp_locks PROGBITS 0000000000000000 00047914
0000000000000128 0000000000000000 A 0 0 4
[16] .rela.smp_locks RELA 0000000000000000 0006a570
00000000000006f0 0000000000000018 35 15 8
[17] .modinfo PROGBITS 0000000000000000 00047a3c

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21


[root@localhost bin]# modinfo appex_module.ko
filename: /serverspeeder/bin/appex_module.ko
author: AppEx Networks
license: AppEx
rhelversion: 7.1
srcversion: 533BB7E5866E52F63B9ACCB
depends:
vermagic: 3.10.0-229.1.2.el7.x86_64 SMP mod_unload modversions
parm: packetPoolSizeKP:uint
parm: pmtuTimeoutMS:uint
parm: shortRttMS:uint
parm: engineId:int
parm: cpuId:int
parm: cpuMaskNum:int
parm: gApxPcapMaxBufLen:int
parm: gApxTraceMaxBufLen:int
parm: gApxTraceFileLen:ulong
parm: uapiUid:uint
parm: uapiGid:uint
parm: uapiPerm:uint
